Adding custom SOLIDWORKS electrical routing components to the Design Library

The Routing Component Wizard, included in the Routing Library Manager, can be used to add intelligence to components and provides all the steps needed to add the mandatory and optional routing features. You can also create custom components that have routing information which automatically start a route just like the ones already included in the Design Library. If you have the SOLIDWORKS Routing Add-in, you can add intelligent custom components to the library. This default library is called the Design Library.

Included in SOLIDWORKS is an extensive library of intelligent components you can drag and drop into your route.

Routing is an application included in SOLIDWORKS Premium that helps automate different types of routes, including electrical.
